24 Port Fast Ethernet PoE Switch

Overview
Specification

Overview

Featuring 24x10/100Mbps PoE+ ports which support IEEE802.3AF/AT standard and 2x1000Mbps Uplink and 2 SFP ports. The PoE+ switch provides Maximum power budget of 250W and 30W for single PoE+ ports sepectively, allowing users to have several different Networking products configured.

Model :AEIN-PS24FE2GC
PoE Standard: AF/AT PoE+ standard
Type: Unmanaged
PoE+ port:24 x 10/100 PoE+ ports
Combo Uplink:2x10/100/1000 combo uplink ports
Surge Protection:6 KV
Total Power Budget: 250 W
Warranty: 3 Years

Datasheet

Got any Questions?

Inquire Now

Connector	16 x 10/100/1000BASE-T RJ45 auto MDI/MDIX ports 2 x 10/100/1000BASE-T RJ45 auto MDI/MDIX ports 2 x 1000 Base-X SFP Slots
PoE+ Port	16 x 10/100/1000Mbps PoE+ PSE port
SFP	Single fiber/Dual fiber supported. Distance vary the module
Thermal Fan	Fanless Design
LED indicators	Power Indicator: PWR(green). Network Indicator: Link(yellow) PoE+ Working Indicator: PoE+(green)
Switch Architecture	Store and Forward
Transmission model	IEEE802.3X full-duplex and Backpressure half-duplex
Switch Performance	Backplane bandwidth : 64Gbps Packet forwarding rate : 35.71Mpps MAC address : 16k
Power requirement	AC100-240V 50/60Hz
ESD Protection	6KV ESD
Dimension(W×D×H)	440mm x 180mm x 44.5mm (17.32in x 7.09in x 1.75in)
Weight	2.5 kg

Datasheet
