Specification
| Model | AEIN-PS24FE2GC |
| Hardware Specifications Connector |
24*10/100BASE-T RJ45 auto MDI/MDIX ports 2*10/100/1000BASE-T RJ45 auto MDI/MDIX ports 2*1000 Base-X SFP Slots |
| PoE+ Ports | 24 × 10/100Mbps PoE+ PSE ports |
| LED Display |
Power Indicator: PWR (green) Network Indicator: Link (yellow) PoE+ Working Indicator: PoE+ (green) |
| Thermal Fan | Fanless Design |
| LED Indicators |
Power Indicator: PWR (green) Network Indicator: Link (yellow) PoE+ Working Indicator: PoE+ (green) |
| Switch Architecture | Store and Forward |
| Transmission Mode | IEEE802.3X full-duplex and Backpressure half-duplex |
| Switch Performance |
Backplane Bandwidth: 12.8Gbps Packet Forwarding Rate: 9.52Mpps MAC Address: 8K |
| Power Requirement | AC 100~240V 50/60Hz |
| ESD Protection | 6KV ESD |
| Dimensions (W×D×H) | 440mm × 290mm × 44.5mm (17.32in × 11.42in × 1.75in) |
| Weight | 3kg |
| Network Standard |
IEEE802.3i 10 BASE-T IEEE802.3u 100 BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3z Gigabit SX/LX IEEE802.3x Flow Control IEEE802.3AF Power over Ethernet IEEE802.3AT Power over Ethernet IEEE802.3AZ EEE |
| PoE+ Standard |
IEEE802.3af Power over Ethernet (PSE) IEEE802.3at Power over Ethernet Plus (PSE) |
| PoE+ Supply Type | 1/2(+) & 3/6(-) End-span |
| PoE Power Output |
Per Port 52V DC 300mA, max. 15.4W (IEEE 802.3af) Per Port 52V DC 600mA, max. 30W (IEEE 802.3at) |
| PoE+ Power Budget | 250W |
| Safety | FCC Part 15 Class A, CE, RoHS |
| Environmental Specification |
Operating Temperature: -10°C ~ 45°C, Humidity: 10% ~ 90% Storage Temperature: -20°C ~ 70°C, Humidity: 5% ~ 95% |
