Specification
| Model | AEIN-PS1010PRO |
| Hardware Specifications Network Connector |
8 × 10/100BASE-T RJ45 auto MDI/MDIX ports 2 × 10/100/1000BASE-T RJ45 auto MDI/MDIX ports |
| PoE+ Port | 8 x 10/100Mbps PoE+ PSE port |
| LED Display |
Power Indicator: PWR (green) Network Indicator: Link (yellow) PoE+ Working Indicator: PoE+ (green) |
| Thermal Fan | Fanless Design |
| LED indicators | Power Indicator: PWR(green). Network Indicator: Link(yellow) PoE+ Working Indicator: PoE+ (green) |
| Switch Architecture | Store and Forward |
| Transmission Model | IEEE802.3X full-duplex and Backpressure half-duplex |
| Switch Performance |
Backplane Bandwidth: 7.6Gbps Packet Forwarding Rate: 4.2Mpps MAC Address Table: 4K |
| Power Requirement | AC100-240V 50/60Hz |
| ESD Protection | 6kV ESD |
| Dimensions (W × D × H) | 220mm × 150mm × 44mm |
| Network standard | IEEE802.3i 10 BASE-T IEEE802.3u 100 BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE802.3x Flow Control IEEE802.3AF Power over Ethernet IEEE802.3AT Power over Ethernet IEEE802.3AZ EEE |
| PoE+ Standard | IEEE 802.3AF Power over Ethernet/PSE IEEE 802.3AT Power over Ethernet Plus/PSE |
| PoE+ Supply Type | 1/2(+), 3/6(-) End-span |
| PoE+ Power Output | Per Port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3AF) Per Port 52V DC, 600mA. max. 30 watts (IEEE 802.3AT) |
| PoE+ Power budget | 120W |
| Special Features | AI Detect and Reboot IPC, APs and PDs Intelligent PoE Port Priority Mechanism |
