Specification
| Product Name | 6 Ports 100M PoE+ Switch | |
| Model | AE-ECO1106FE | |
| Interface | PoE+Ports | 1-4:10/100Mbps RJ45 Ports |
| Uplink Ports | 5-6: 100Mbps RJ45 Uplink Ports | |
| PoE Power Supply | MAX PoE Output | 30W |
| Total Power Supply | 65W | |
| Priority Function | Support | |
| LED | Power, Link/Act | |
| Processing Types | Store-and-Forward | |
| Half-duplex back pressure and IEEE802.3x full-drplex flow control | ||
| Performance Specification | Bandwidth | 1.2Gbps |
| Packet Forwarding Rate | 0.89Mpps | |
| MAC Address | 2k | |
| Network Standards |
IEEE802.31 10BASE-T IEEE802.3u 100BASE-TX IEEE802.3x Flow Control IEEE802.3az EEE | |
| Power Input | 90-264V AC - CE Certified | |
| Size | 200mm(L) 133mm(w)*44mm(H) | |
| Cables | UTP Category 5 or above cable | |
| Environmental Specification |
Working Temperature: 0°C - 50°C, Humidity: 10% - 90% non-condensing Storage Temperature: -20°C - 70°C, Humidity: 5% - 95% non-condensing | |
