Specification
| Model | AE700-IPS8GE4GF-M |
| Port description | 8 x ethernet port (PoE+) 1000BASE-T 4 x optical port (SFP) 1000BASE-X |
| Optical port characteristics | Interface type: SFP Speed: 1000Mbps Wavelength: Single-mode fiber: 1310nm/1550nm Multimode fiber: 850nm Core standard: Single mode: 8.3μm, 8.7μm, 9μm, 10μm Multimode 50μm, 62.5μm, 100μm |
| Electrical port characteristics | Interface type: PoE+ Rate: 10/100/1000Mbps adaptive Duplex mode: full/half duplex Connection mode: MDI/MDIX automatic flip |
| Protocol standard | IEEE802.3i 10 BASE-T IEEE802.3u 100 BASE-TX IEEE802.3ab 1000 BASE-T IEEE802.3z 1000 BASE-LX IEEE802.3af Power over Ethernet IEEE802.3at Power over Ethernet IEEE802.3x Flow Control IEEE802.3az EEE |
| Exchange performance | Input power: DC 48~56V (6PIN Phoenix terminal), 1*DC interface Power consumption: full load <6W (not including PoE) Dual power supply: support Redundant protection: support Reverse connection protection: support |
| Power supply | Input power: DC 48~56V (6PIN Phoenix terminal), 1*DC interface Power consumption: full load <6W (not including PoE) Dual power supply: support Redundant protection: support Reverse connection protection: support |
| Mechanical structure | Shell material: metal Protection level: IP40 Size: 153*130*44mm (Excluding connector protruding part and DIN rail assembly size) Weight: 1.25Kg Installation method: DIN Rail installation |
| Surroundings | Working temperature: -40℃~75℃ Storage temperature: -40℃~85℃ Relative humidity: 5%~95% RH (non-condensing) |
| Industry Standard | EMI: CE/FCC EMS: IEC61000-4-2 (ESD-static) IEC61000-4-3 (RS-radiation anti-interference) IEC61000-4-4 (EFT-fast burst) IEC61000-4-5 (Surge-lightning protection) IEC61000-4-6 (CS-conducted anti-interference) Machinery: IEC60068-2-6 (vibration) IEC60068-2-27 (Shock) IEC60068-2-32 (free fall) Industry: IEC61000-6-2 Railway: EN50155, EN50121-4 Transportation: NEMA TS-2 |
| Warranty | Warranty period: 3 years |
| Hardware watchdog | Stand by |
| PoE management | Support PoE total power settings Support single port PoE power settings Support port PoE power supply priority design Support custom PoE power supply time |
| Loop protection | Support ERPS Ring protection Support 50ms healing looping Support BPDU protection, root protection and loopback protection |
| Link aggregation | Link aggregation Support link aggregation (LACP) Support static polymerization, dynamic aggregation Support for maximum support for 8 aggregation groups Support for source port, source MAC, destination MAC, source IP, destination IP, source IP port, destination IP port |
| Summing tree (STP) | Support STP (IEEE 802.1d), Support RSTP (IEEE 802.1w) Support edge port Support spanning tree BPDU packet statistics Support root bridge protection, TC protection, BPDU protection, BPDU filtering |
| DHCP | Support DHCP server Support DHCP Snooping Support Option82 |
| VLAN | Support 802.1q VLAN Maximum support 4094 Support QinQ Support Mac VLAN Support GVRP protocol Support GMRP protocol Support 1: 1 and N: 1 VLAN mapping function Support three port modes: Access, Trunk, and Hybrid, Translation, QinQ Including the foundation in Qinq and flexible in QinQ |
| Security feature | Based on user grading management and password
protection Support for port numbers, IP addresses, MAC addresses limit users access Support HTTPS, SSH V1 / V2, SSL V1 / V2 Support IP-Mac-Port-VLAN binding Support ARP protection, IP source protection, DOS protection Support DHCP Snooping, DHCP Attack Protection Support 802.1x certification, Support port security, port isolation Support port alarm |
| Access Control (ACL) | Supports L2 (Layer 2) ~ L4 (Layer 4) package filter function Support port mirror, port redirection, flow rate, QoS marking Support Mac ACL Support IP ACL |
| Service quality (QoS) | Support 8 port queues Support port priority, 802.1p priority, DSCP priority Support SP, WRR, WFQ priority scheduling algorithm |
| Multicast | Support fast leaving mechanism Support static multicast group, dynamic multicast group Support IGMP Snooping Support multicast filtering, packet statistics, unknown multicast discard |
| Management and maintenance | Support Web network management (HTTP, HTTPS, SSL V3,
TLS V1) Support CLI (Telnet, SSH V1 / V2, local serial port) Support SNMP V1 / V2 / V3, compatible public MIBS Support LLDP, RMON Support SNTP Support CPU monitoring, memory monitoring Support system log, hierarchical warning, support remote log server Support port alarm Support HTTP software upgrade, configuring backup import Support TFTP upgrade |
